1、The touching screen with statistics, the statistical data can be download,the quality of  the products can be traced back

2、The probe walk path can be projected freely

3、Industrial-grade detecting host,it can last time and work reliably and stably

1、The range of frequency：64 Hz～2 MHz

2、gain：0～48dB stepping is 0.5dB

3、Phase position rotation：0~360° stepping  1 °

4、Ratio of gains（Y/X）：0.1~10

5、Inside and outside clock can signal transfer output simultaneously

6、High accuracy end socket、signal excision function

7、High accuracy real time 、delayed alarm output

8、Unequal amplitude phase position/ amplitude alarming area

9、Full digital computer parameter adjustment

10、Soft disk and hard disk saving and  reappear detecting signal

11、Quick figure/ analog electronics balance

12、Equipped with memory trace delaying blanking function

13、Menu type man-machine dialogue

14、Broadband digital filtering restrains the effects of the change of speed on signal amplitude,consequently ,it is very suitable for manual detection and automatic detection

15、Automatic signal amplitude、phase position measuring and eddy detecting signal playback and analysis function

16、Saving amount of every kind of detecting data,graph and other detective results

working temperature ：-15~55℃

saving temperature ：-20~60℃

relative humidity:not exceed 85%

working voltage :AC220±10V
