1、It adopts double frequency and double channel to test workpiece

2、Searching flaw and hardness sorting will be finished in one process

3、It can test flaw in the depth 0.05mm

4、The speed of testing is lower than one piece in two seconds

5、Equipment noise<60db。Power consumption <500W /220V

6、Supplying sorting and counting automatically

7、The parts are not damaged after eddy current flaw detection

8、It does not need to be washed、demagnetized after testing

9、Count up the number of all workpiece and qualified products and percent of pass

1、Frequency range:64Hz-2MHz

2、Gain :0-48db，stepping is 0.5db

3、Phase position：0-360°、stepping is 1°

4、Independent optional frequency

5、Model setting with different style

6、Automatic phase position  ,amplitude analysis

7、Automatic zero calibration system,it can set time interval of zero calibration

8、Different styles alarm area setting , it can be applied to every modes

9、Ratio of gains（Y/X）：0.1-10

10、Clear screen automatically /tracking impedance

11、It can test signal playback ,saving

12、Fast simulation /digital electric automatic balance and dynamic tracking smoothing

13、Operating interface is simple and intelligent ,very easy to operate

14、It is suitable for every probe

15、It suitable for metal tube ,rods production and offline quality testing

16、Quick number

17、 Unequal amplitude 、Dissymmetrical phase position alarm area setting

18、 Many kinds of showing ways: impedance time base

19、 Digital smoothing

20、Voice light alarm output

21、 Automatic balance time

22、 Inside and outside clock selection

23、 It can save all kinds of testing procedures and testing database

24、The eddy current signal can playback or extend

25、 Recording showing flaw automatically

26、Showing ways: full line , blanking

27、Blanking Showing coefficient：1～100

28、Background option from rectangular coordinate system and polar coordinate system

29、Calendar and time showing

30、 Liquid crystal display

31、Simulating electric balance

32、Testing amplitude 、phase position ,digital value of flaw

working temperature :-15~55℃

saving temperature:-20~60℃

relative humidity : not exceed 85%

working voltage :AC220±10V
